AlphaPower 510W German Monocrystalline Silicon Solar Panel

**NO Return! ***Product (s) cannot be returned once ordered.
Customers are requested to check the product before ordering.

AlphaPower 510W German Monocrystalline Silicon Solar Panel for All Purposes

Key features:

*96 German Monocrystalline Silicon Cells
*Positive tolerance up to 5W
*High Efficiency
*PID Resistant
*Low-light Performance
*Severe Weather Resilience
*Durability Against Extreme Environmental Conditions
*High Transmission, Low Iron Tempered Front Glass
*Anodized Aluminium Alloy
*IP67 Rated Junction Box
*TUV/IEC61215/IEC61730/CEC/CE/PID/ISO/INMETRO Certified
*900mm PV Cable
MC4 Connector

Mechanical Characteristics:
-Cell type: Monocrystalline SiliconPERC 156*156*(6inch)
-No. of Cells: 96 (8*12)
-Size/ Dimension: 1956*1310*45mm (77.01*51.58*1.77 inch)
-Weight: 26.5 kg (58.4 lbs)
-Front Glass: High Transmission, Low Iron, Tempered Glass
-Frame: Anodized Aluminium Alloy
-Junction Box: IP67 Rated
-Output Cable: TUV 1*40mm
-Length: 900mm or Customized Length

Specifications:

Maximum Power( Pmax): 510W
Maximum Power Voltage: 48.5V
Maximum Power Curren (Imp): 10.51A
Open Circuit Voltage (VoC): 59.5V
Short Circuit Current (Isc) : 10.72A
Module Efficiency STC (%): 19.90%
Operating Temperature (C): -40C~+85C
Maximum System Voltage: 1000VDC or 1500VDC
Maximum Series Fuse Rating: 20A
Power Tolerance: 0~+3%
Temperature Coefficients of Pmax: -0.39%/C
Temperature Coefficients of Voc: -0.29%/C
Temperature Coefficients of Isc: 0.048%/C
Normal Operating Cell Temperature (NOCT): 45+-2C
PV Cable: 900mm
Connector: MC4

Description:
-Positive Tolerance up to 5W delivers higher output reliability.
-Higher Module Conversion Efficiency (up to 19.90%) benefit from Passivated Emmiter Contact (PERC) technology.
- Eagle modules pass PID test, limited power degradation by PID test is guaranteed for mass production.
- Advanced Glass and Solar Cell SurfaceTexturing Allow for Excellent Performance in Low-light Environments.
-Certified to withstand; wind load (2400 Pascal) and Snow load (5400 Pascal).
- High Salt Mist and Ammonia Resistance Certified by TUV NORD.
- TUV/IEC61215/IEC61730/CEC/CE/PID/ISO/INMETRO Certified Product.
-Suitable for Car Batteries, Car, Bus, Recreational Van (RV)/ Moving Van, Boat, Ship, Aircraft, Satellites, Space Stations, Outdoor breeding, Indoor Plantation, Incubator, Irrigation, Tourism, Solar street lamp, Home Appliances, Water Pump, etc.

Warranty: 05 Years Product Warranty, 10 Years Linear Power Warranty. No Burn, No Physical Damage, No Abuse or Misuse, No Alternation will be accepted for Warranty Service.
